PRO-PHY150-5SI3-...
5-Channel Hybrid Combiner with single isolator
DESCRIPTION
The PRO-PHY series of hybrid combiners has been designed to help
identify the optimum solution for combining several transmitters into
one antenna.
All hybrid combiners are suitable for 19” rack mounting.
Single isolators fitted as standard.
A range of racks and cabinets are available.
Option: Maximum input power of 35 W (PRO-PHY150-5SI3-35)
or 100 W (PRO-PHY150-5SI3-100).
ORDERING DESIGNATIONS
TYPE PRODUCT NO.
PRO-PHY150-5SI3-35 210000916
PRO-PHY150-5SI3-100 210000917
Please specify the frequencies for TX when ordering.
SPECIFICATIONS
ELECTRICAL
MODEL PRO-PHY150-5SI3-...
TX FREQUENCY 136 - 175 MHz
MAX. INPUT POWER 35/100 W
TX-TX SPACING, Δ TX
< 7 MHz
TYP. INSERTION LOSS 8.6 dB
TX-TX ISOLATION > 100 dB
IMPEDANCE Nom. 50 Ω
SWR ≤ 1.5
MECHANICAL
TEMP. RANGE –30° C → +60° C
CONNECTORS N-female
DIMENSIONS (L x W x H) 400/500 x 483 x 133 mm
WEIGHT Approx. 7.3/11.8 kg
PROCOM A/S reserve the right to amend specifications
without prior notice.
18/09/12
