FSP 2/...-FME
“StraightFlex” Antenna with Universal FME-Connection
System for Portable Equipment in the 2 m Band
DESCRIPTION
Highly flexible, polyethylene covered StraightFlex steel wire.
Full size ¼ λ antenna whip.
Highest quality materials in an elegant and slender design.
Delivered factory tuned and tested to ensure minimum SWR and
optimum performance.
Provided with universal FME-connection system for optimum flexibility
and easily exchangeable connectors.
Designed for use with the following of Procoms line of black FME-
connectors (to be ordered separately): BFME-UHF, BFME-BNC, BFME-
TNC, BFME-N, BFME-EBNC and BFME-ETNC.
ORDERING DESIGNATIONS
TYPE PRODUCT NO. FREQUENCY
FSP 2/l-FME 140000113 144 – 164 MHz
FSP 2/h-FME 140000095 155 – 175 MHz
SPECIFICATIONS
ELECTRICAL
MODEL FSP 2/...-FME
ANTENNA TYPE ¼ λ antenna for portable equipment
FREQUENCY 2 m band covered by two models
IMPEDANCE Nom. 50 Ω
POLARIZATION Vertical
GAIN 0 dB (equal to a ¼ λ portable antenna)
BANDWIDTH ≥ 20 MHz @ SWR ≤ 2.5
SWR < 2 when mounted directly on portable equipment
MAX. POWER 100 W
MECHANICAL
MATERIALS Polyethylene covered flexible steel wire
Black-chromed brass
COLOUR Black
TOTAL HEIGHT Approx. 490 mm (dep. on type)
WEIGHT Approx. 35 g
CONNECTOR FME (female) (Exchangeable BFME-connectors
to be ordered separately)
RECOMMENDED BFME-CONNECTORS
(To be ordered separately)
PLEASE NOTE
The FSP 2 is also available with SMA male connector and different thread
studs, but in this case with fixed, non-exchangeable connector (not
FMEconnection system). Information on these special versions on request.
PROCOM A/S reserve the right to amend specifications
without prior notice.
03/04/13
