Procom PLPI-TETRA-... User Manual
Plpi/tetra

PLPI/TETRA/...
Indoor Linearly Polarized Patch Antennas for mounting on
Wall or Ceiling
DESCRIPTION
Low-profile antenna for the 380 - 470 MHz band.
PLPI/TETRA/... is a patch antenna for indoor use.
Specially designed for closed rooms.
Covers 50 MHz with a radiation of approx. 7 dBi.
The antenna is carefully sealed with a discreet cover.
The connector is placed at one side to enable mounting close to a wall
or a ceiling.
Including mounting bracket.
ORDERING DESIGNATIONS
TYPE
PRODUCT NO.
FREQUENCY
PLPI/TETRA/s-f
100000423
380 - 430 MHz
PLPI/TETRA/l-h
100000445
430 - 470 MHz
SPECIFICATIONS
ELETRICAL
MODEL
PLPI/TETRA/...
ANTENNA TYPE
Linearly polarized patch antenna
FREQUENCY
380 - 470 MHz covered by two models
IMPEDANCE
Nom. 50 Ω
POLARIZATION
Linear
GAIN
Approx. 7 dBi
BANDWIDTH
≥ 50 MHz @ SWR ≤ 2
HALF POWER BEAMWIDTH
Approx. 80° (H- and E-plane)
SWR
≤ 1.2 f.res.
MAX. POWER
100 W
ANTISTATIC PROTECTION
All metal parts DC-grounded
(Connector shows a DC-short)
MECHANICAL
CONNECTOR
N-female
COLOUR
Marine white
MATERIALS
Cover: ABS (white)
Chassis: Aluminium
SIZE (L x W x H)
Approx. 340 x 340 x 60 mm
WEIGHT
Approx. 2.3 kg
MOUNTING
For mounting on wall or ceiling
ø5 mm (three holes) (see mounting details)
