Specifications
38
Solid State @ 100% – LINE IN TO LINE OUT
THD+N (min gain, 1 kHz, 20 kHz BW) -101 dB (0.0009%)
THD+N (max gain, 1 kHz, 20 kHz BW) -70 dB (0.03%)
SNR (min gain, 1 kHz, A-wgt, 20 kHz BW) 110 dB
SNR (max gain, 1 kHz, A-wgt, 20 kHz BW) 82 dB
Low Cut Filter
Type Bessel 2nd Order
Corner Frequency 75 Hz
Attenuation (20 Hz) -23 dB
Pad
Attenuation 15 dB
Phase
Phase Shift 180 deg
Phantom Power
Phantom Power Current (per jack) 10 mA
Voltage 48V ± 1V
Compressor
Threshold 10 dBu
Compression Ratio 4:1
Fast Attack Time 0.3 ms
Fast Release Time 100 ms
Slow Attack Time 2.0 ms
Slow Release Time 1100 ms
Limiter
Threshold 17 dBu (= -3 dBFS)
Attack Time 0.075 ms
Release Time 100 ms
Send/Return
Send Level, Max (bal) 20 dBu
Return Level, Max (bal) 20 dBu
Send Level, Max (unbal) 14 dBu
Return Level, Max (unbal) 20 dBu
Analog Meter
Switch, GR Comp. Gain Reduction
Switch, Drive Tube Stage Drive
Switch, Level Output Level
Level, 0 dB VU, Drive Mode 12 dBu
Level, 0 dB VU, Output Mode 4 dBu
(Continued)
