DCS Remote Preamp: Base
MIC INPUTS – sends
microphone signal to the
Remote Preamp (Page 2)
DI INPUTS – sends
instrument or line level
signals to the Remote
Preamp via TS or TRS cable
(Page 2)
PRE OUTPUTS – sends
amplified signal out of the
Remote Preamp to your
recorder or mixer (Page 2)
CUE OUT – sends
headphone mix out to
headphones (Page 2)
C IN – Accepts a balanced
stereo input from your DAW
(page 2)
CUE IN – Accepts 1/4"
unbalanced stereo input
from any DAW or laptop
phones output (page 2)
IEC Power WARNING –
Unit operates under fixed
voltage and will be
damaged by incorrect
input voltage! (page 2)
