Specifications
_______________________________________________________________________
- 3
3 -
Input Impedance
600
, bridged T-control (floating)
Output Load Impedance
600
(floating)
Frequency Response
20 Hz to 20 kHz ± 1 dB
Gain
45
dB,
± 1 dB
Distortion
> 0.5% T.H.D. from 50 Hz – 15 kHz
with limiting, at 1.1 seconds release setting.
Output of +22 dBm with no greater than 0.5% T.H.D.
Signal-to-Noise Ratio
> 81 dB with input signal at threshold of limiting,
over a bandwidth of 30 Hz to 18 kHz
Attack Time
Adjustable, from 20 to 800 microseconds, plus 10ms
“Slo” mode
Release Time
Adjustable, from 50 milliseconds to 1.1 seconds
Threshold vs. Output Level
External Connections
XLR / Original Jones barrier strip
Stereo Interconnection
Optional, using 1176SA stereo interconnect accessory
Power Requirements
115V/230V
Power Connector
Detachable IEC power cable.
Fuse
125 mA time delay (slow blow) / 115 V
63 mA time delay (slow blow) / 230 V
Dimensions
19" W x 3.5" H x 12.25" D (two rack unit)
Weight
11 lb. (with box, 14.5 lb.)
Ratio Input Level at +2 dB
Relative Output -25 dB
20:1
-25 dBm
+13 dBm
8:1
-26 dBm
+11 dBm
4:1
-32 dBm
+6 dBm
2:1
-35 dBm
+4 dBm
