Interconnections
__________________________________________________________
- 8 -
(Illustration goes here)
(Interconnection illustration—should show 1176AE in standard insert send/return configuration with
patch bay, using XLR and, optionally, terminal strip connections)
For most applications, we recommend starting with the 1176LN INPUT and OUTPUT knobs
set to approximately 24 (their 12 o’clock position) for unity gain.
