Page 4
4
SINGLE HANDLE KITCHEN FAUCET
N160 01
PARTS LISTING
XX designates finish matched parts
A504713
Weight
19
A66D614NXX
Spray Hose
18
A008048
Screw(5/32" -32 * 1/4" L)
17
A667295XX
Base Trim Ring
16
A519204N
Check Valve
15
A66D178N
Shank Adaptor Assembly
14
A054062
Lock Nut
13
A66D098ZN
Mounting Hardware
12
A603707N
Supply Pipe- Cold
11
A603708N
Supply Pipe- Hot
10
A663843
Base Mounting Hardware
9
A66F106XX
Cover plate & Putty Plate
8
A523444NXX
Hand Spray W/ Check valve
7
A126999KP
Hose Guide
6
A66D771-50XX
Handle Cap
5
A029625XX
Metal Handle
4
A103016XX
Trim Cap
3
A104261
Locking Nut
2
A507348N
Ceramic Disc Cartridge
1
Part No.
Part Name
No.
