#SS-00313, v.05
Printed in U.S.A. | © TOTO LTD. 07/09 | Printed on recycled paper ♻
Ph: (888) 295-8134 | Fax: (800) 699-4889 | www.totousa.com
FBY1525
Enameled Cast Iron Bathtub
SPECIFICATIONS
• Size 59-3/4"L x 32"W
• Depth 16-3/4"
• Warranty Lifetime Limited Warranty
• Material Enameled Cast Iron
• Shipping Weight 397 lbs.
• Shipping Dimensions 62-5/8"L x 34-13/16"W x
20-1/4"H
These dimensions and specifi cations are subject to change without notice
59-3/4" (1517mm)
53-1/16" (1347mm) 2-3/4" (70mm)
26-1/8" (663mm)
2-15/16" (75mm)
ш2-3/16" (ш55mm)
16" (406mm)
32" (813mm)
7 7/8" (200mm)
15-1/4" (387mm)
3/16 (4mm)
12-7/8" (327mm)
30-1/2" (774mm)
3/16" (4mm)
3/8" (10mm)
16-5/16" (415mm)
8-3/8" (212mm) 8-3/8" (213mm)
ш2-3/8" (ш60mm)
2-3/4" (70mm)
3/8" (10mm)
16-3/4" (425mm)
INSTALLATION NOTES
Floor support under bath must provide a minimum of
80 lbs/square foot (391 kg/square meter) loading.
