ENGLISH
ENGLISH
12 MAINTENANCE & CARE
11
12 CARTRIDGE REPLACEMENT
Turn off water supplies and relieve pressure before working on your faucet. Remove handle
(see figure 11). Remove the Dome Cap (12A) by unscrewing counterclockwise. Using
pliers, unscrew the retainer ring (12B). Carefully remove the Cartridge (12C) by pulling it
straight up and out. Reassemble valve by reversing steps.
CAUTION: Maintenance
DISASSEMBLY
1.
Replacement parts may be available at the store where you purchased
your faucet.
2. When replacement parts are not available, please write or call Price
Pfister Consumer Service.
3. Always turn off water and relieve pressure before working on your
faucet.
NOTE: Trim Care
Cleaning Instructions:
For all Handles and decorative finishes, use only a soft damp
cloth to clean and shine. Use of polish, detergents, abrasive
cleaners, organic solvents or acid may cause damage. Use of
other than a soft damp cloth will nullify our warranty!
Special Trim:
Trim products which contain Porcelain or other similar
substance are not acceptable for public areas or Commercial
use. Installation of Said Trim is at Users Risk!
1–800–PFAUCET (1–800–732–8238)
For Toll-Free Pfaucet information call
1–800–PFAUCET (1–800–732–8238)
or visit www.pricepfister.com
• Installation Support
• Care and Warranty Information
11 HANDLE REMOVAL
Using a 3 / 32 ” Hex wrench, loosen Set Screw (11A) and remove Handle (11B).
4
11B
11A
12A
12B
12C
