3
ROMAN TUB FAUCET
SCRT500
PARTS LISTING
No Part Number Part Name Q'ty
1 A663689xx Handle Cap 2
2 A004001N O-Ring (Φ5/16" ID * Φ7/16" ID) 2
3 A008087 Screw (3/16" -24 * 9/16" L) 2
4 A66E218xx Metal Handle 2
5 A008191 Screw (M4 * 5 mm L) 2
6 A018191xx Handle Base 2
7 A66D545 Handle Trim Ring 2
8 A063053 O-Ring (Φ1-3/4" ID *Φ1-15/16" OD) 2
9 A126108 Fixing Set 2
10-a A507972 Ceramic Disc Cartridge-Cold 1
10-b A507971 Ceramic Disc Cartridge-Hot 1
11 A002639 Handle Valve Body 2
12 A66D401 Mounting Hardware Assembly 2
13 A077034 Threaded Connector 2
14-a A012024C Handle Valve Body Indicator Clip-Hot 1
14-b A012024H Handle Valve Body Indicator Clip-Cold 1
15 A124404xx Lift Rod 1
16 A048044 O-Ring (Φ3/16" ID * Φ5/16" OD) 1
17 A139826xx Spout 1
18 A66D449 Adaptor Assembly 1
19 A072048N O-Ring (Φ1-1/16" ID * Φ1-1/4" OD) 1
20 A004107 O-Ring (Φ1-9/16" ID * Φ1-11/16'' OD) 1
21 A603582 Aerator 1
22 A603236 Nut & Seal 1
23 A105137 Supply Hose 1
24 S2211E01xx Hand Shower W/Check Valve 1
25 A66F031xx Spray Holder Assembly 1
26 A134036xx Shower Hose 1
27 A031003 Hex Wrench(H2 * 17 mm L * 49 mm L) 1
28 A203000 Pipe Tape 1
XX designates finish matched parts
