4
ROMAN TUB &SHOWER FAUCET
RT300
PARTS LISTING
xx designates finish matched parts.
NO Part Name Part Number Q'ty
1 Handle Cap A66D422×× 2
2 O-Ring(Φ1/4" ID * Φ3/8" OD) A048089 2
3 Screw (3/16" -24 * 7/16" L) A008283×× 2
4 Metal Handle A662572×× 2
5 Handle Base A018073 2
6-a Ceramic Disc Cartridge-Cold A507376N 1
6-b Ceramic Disc Cartridge-Hot A507375N 1
7 Handle Trim Ring A66D423 2
8 O-Ring (Φ1-5/8" ID * Φ1-13/16" OD) A072032N 2
9 Mounting Hardware A66D424×× 2
10-a Handle Valve Body -Cold A002544C×× 1
10-b Handle Valve Body -Hot A002544H 1
11 Spout A139720 1
12 Lift Rod A66D448 1
13 Screw (M4 * 5 mm L) A008191 1
14 Spout Trim Ring A071342×× 1
15 Adaptor Assembly A66D449 1
16 O-Ring (Φ1-1/16" ID * Φ1-1/4" OD) A072048N 2
17 O-Ring (Φ1-9/16" ID * Φ1-11/16'' OD) A004107 1
18 Mounting Hardware A66D450 1
19 O-Ring (Φ1/8" ID * Φ1/4" OD) A004559N 2
20 Spout Valve Body A501371 1
21
Hex Wrench(H2 * 17 mm L * 49 mm L) A031003 1
22 Hand Shower W/Check Valve S2211195×× 1
23 Spray Holder Assembly (3-3/4''L) A604627×× 1
24 Shower Hose A134036×× 1
25 Supply Hose A105137 1
