SPECIFICATIONS
• Water Use 1.6 GPF & 0.9GPF
(6.0 LPF & 3.4LPF)
• Flush System Dual-Max
• Min. Water Pressure 8 psi (fl owing)
• Water Surface 6" x 4-1/2"
• Trap Diameter 2-1/8"
• Rough-in 12"
• Trap Seal 2-1/8"
• Warranty One Year Limited Warranty
• Material Vitreous china
• Shipping Weight CT412F - 80lbs
ST412M - 30lbs
• Shipping Dimensions CT412F
30-3/4" L x 17-3/8" W
x 20-1/2" H
ST412M
17-1/4" L x 7-7/8" W
x 17-1/2" H
CST412MF
Aquia ® Close Coupled Toilet, 1.6GPF & 0.9 GPF
5-1/2"
(140mm)
14-1/4"
(362mm)
18-1/2"(470mm)
27-1/2"(700mm)
(7
17-1/8"
(435mm)
16-1/8"
(410mm)
12" (305mm)
3/4" (19mm)
31-1/4"
(794mm)
15-3/8"
(390mm)
6"
(152mm)
7-3/4"
(197mm) 10"
(254mm)
Double Sanitary Tee / Sanitary Cross Double Combination Wye / 1/8 Bend
YES NO
# SS-00455 V.03
Printed in U.S.A. | © TOTO USA 12/09 | Printed on recycled paper ƛ
Ph: (888) 295-8134 | Fax: (800) 699-4889 | www.totousa.com
INSTALLATION NOTES
Back-to-Back Toilet Installations:
TOTO recommends the use of a nationally listed,
double sanitary tee-wye only, in vertical waste stacks,
in accordance with the stipulations noted in the
majority of nationally recognized plumbing codes.
These dimensions and specifi cations are subject to change without notice
