Factory Direct Hardware Toto MS990CGR Neorest - Manual (Page 2)

TOTO U.S.A., INC. • 1155 Southern Road, Morrow, GA 30260 • Tel. (888) 295-8134 • Fax. (770) 282-8701 • www.totousa.com
Printed in U.S.A. © TOTO LTD. 05/05 #A10075 PRINTED ON RECYCLED PAPER
REV. 03/07
SPECIFIC Power Rating 120V AC, 60 Hz.1277W
Power Cord Maximum length: 3 ft
Water Feature Adjustable Water Flow Rate
Rear washing: from 9 to 14.5 oz/min.
Soft washing: from 9 to 14.5 oz/min.
Front washing: from 9.5 to 14.5 oz/min.
Temperature of Washing Spray
Minimum: 86º F/30º C
Maximum: 104º F/40º C
Safety Features: Temperature fuse,
Bi-metal sensor (auto reset), and
Float switch (prevent boil)
Drying Feature Air Temperature:
High: About 138ºF/59ºC
Medium: About 122ºF/50ºC
Low: About 104ºF/40ºC
Capacity of Air: 10.5 ft 3 /min
Safety Feature: Temperature Fuse
Seat Warming Feature Surface Temperature:
Minimum: 79º F/26º C
Maximum: 97º F/36º C
Seat Heater Capacity: 50W
Safety Feature: Thermal fuse
Deodorizing Feature Method: 0
2
Deodorizer
Air Volume: 5.5 ft 3 /min
Water Supply Pressure Minimum: 20 psi
Maximum: 80 psi
Ambient Temperature Range 33ºF/1ºC to 104ºF/63ºC
Size 17" x 32.2" x 22.2"
Weight Net:108 lbs.
Listings/Approval
Colors: Standard #01 Cotton
Optional #11 Colonial White
#12 Sedona Beige
Specifications may change without notice.
17-5/32"
(436mm)
13"
(330mm)
Footprint
11-3/4"
(300mm)
At least 1 foot (325mm)
Installation position
Power Supply
Power Cord (3ft.)
5-7/8" (150mm)
32-7/8" (835mm)
5-7/8"
(150mm)
22-1/4"
(565mm)
16-1/4"
(413mm)
5/8"
(16mm)
12" (305mm)
26" (660mm)
Drain pipe installation position
Bathroom
Door
Water Supply
1/2" Pipe
Neorest 600 MS990CG
■
SPECIFICATIONS
Water Use: 1.6 Gpf/6.0 Lpf with
alternate 1.2 Gpf/4.5 Lpf
Flush System: Cyclone Siphon Jet
Min. Water Pressure: 20 psi
Water Surface: 11-3/8" x 7-7/8"
Trap Diameter: 2-1/8"
Rough In: 12" rough in
Trap Seal: 2-7/16"
Warranty: Three Year Limited
Warranty
Material: Bowl: Vitreous china
Seat and cover: Plastic
Shipping Weight: MS990CG
120 lbs.
Shipping Dimensions: MS990CG
40-1/4" x 23" x 31-1/8"
Colors: Standard Cotton #01
Colors: Optional Colonial White #11
Sedona Beige #12
Fixture dimensions and hydraulic performance meet
or exceed ANSI/ASME standard A112.19.2M and
CAN/CSA B 45 requirements.
Listing / Approvals: IAPMO/UPC, CSA, City of
Los Angeles, State of Massachusetts, and others.
These dimensions and specifications are subject to
change without notice.
MS990CG
Neorest 600
And others.
