SPECIFICATIONS
MS980CMG
Neorest 550 Elongated Toilet/Bidet
#SS-00163 v.05
Printed in U.S.A. | © TOTO USA 07/10 | Printed on recycled paper ƛ
Ph: (888) 295-8134 | Fax: (800) 699-4889 | www.totousa.com
These dimensions and specifi cations are subject to change without notice
SPECIFIC Power Rating 120V AC, 60 Hz.1281W
Power Cord Maximum length: 3 ft (914 mm)
Water Feature Adjustable Water Flow Rate
Rear washing: from 9.1 to 14.5 oz/min.
Soft washing: from 9.1 to 14.5 oz/min.
Front washing: from 9.8 to 14.5 oz/min.
Temperature of Washing Spray
Minimum: 86º F/30º C
Maximum: 104º F/40º C
Safety Features: Temperature fuse,
Bi-metal sensor (auto reset), and
Float switch (prevent boil)
Drying Feature Air Temperature:
High: About 138ºF/59ºC
Medium: About 122ºF/50ºC
Low: About 104ºF/40ºC
Capacity of Air: 10.6 ft 3 /min
Safety Feature: Temperature Fuse
Seat Warming Feature Surface Temperature:
Minimum: 82º F/28º C
Maximum: 97º F/36º C
Seat Heater Capacity: 50W
Safety Feature: Thermal fuse
Air Purifying Feature Method: 0
2
Deodorizer
Air Volume: 5.5 ft 3 /min
Water Supply Pressure Minimum: 20PSI (0.14MPa) flowing @
5.3gal/min (20L/min)
Max 108PSI (0.75MPa) static
Ambient Temperature Range 33ºF/1ºC to 104ºF/40ºC
Size 15.3” x 25.2” x 21.3”
Weight Net: 82.7 lbs.
R1/2
PLAN VIEW
FRONT VIEW
ON/OFF ON/OFF FLUSH POWER CLEANSING REAR ON/OFF FRONT
REAR
CLEANSING STOP OSCILLATING
ON/OFF
OSCILLATING
ON/OFF REAR
CLEANSING OSCILLATING
ON/OFF FRONT
CLEANSING Soft
PULSATING
ON/OFF
DRYER
ON/OFF PRESSURE POSITION
FULL FL USH
LIGHT FLUSH
4-1/2”
(115mm)
2-3/8”
(60mm)
1-3/4”
(45mm)
26-3/16” (665mm)
3-1/2”
(90mm)
7-7/8”
(200mm)
5-7/8”
(150mm)
24-1/4”
(615mm)
18-3/8”
(466mm)
5-7/16”
(138mm)
4-3/8”
(1
12mm)
1/8”
(5mm)
1/8”
(5mm)
2-9/16” (65mm)
1-7/8” (48mm)
2-3/8”
(60mm)
2-3/8” (60mm)
5-5/16” (135mm)
1-1/4”
(32mm)
5-7/8”
(150mm)
5-1/8”
(130mm)
21-3/8”
(542mm) 14-3/4” (375mm)
1-1/8” (28mm) 1-5/16” (33mm)
6-9/16”
(167mm)
15-5/16”
(389mm)
12”
(305mm)
26-1/2”
(675mm)
3”
(76mm)
1
1
-13/16”
(300mm)
min. 12” (305mm)
Water supply
on the wall
Line designating the
center of the toilet bowl Closet flange
(not included)
Water supply
on the floor
3-1/4”
(80mm)
3-1/4” (80mm) 2-3
/8”
(60m
m)
3-1/4”
(80mm)
3-1/4”
(80mm)
10-1/4”
(260mm)
10-1/4”
(260mm)
4-3/8”
(110mm)
4-1/2”
(115mm)
2
-3/8”
(60mm
)
6-7/8”
(175mm)
4-1/2”
(115mm)
Water supply
on the wall
Line designating the
center of the toilet bowl Closet flange
(not included)
Water supply
on the floor
min. 12” (305mm)
Extended water supply range locations using
the Connection Unit THU9202 (sold separately)
Water Use: 1.6 Gpf/6.0 Lpf with
alternate 1.05 Gpf/4.0 Lpf
Flush System: Cyclone Siphon Jet
Water Supply: Min 8.7gal/min (33L/min)
before installation
Max 80PSI (0.55MPa) static
Water Surface: 10-13/16" x 8-7/16"
Trap Diameter: 2-1/8” (54 mm)
Rough In: 12” rough in
Warning: If there is a base board in the
restroom, the center of the floor drain
should be a minimum of 12” from the
base board.
Trap Seal: 2-7/16” (62 mm)
Warranty: Three Year Limited (Residential)
One Year Limited (Commercial)
Material: Bowl: Vitreous china
Seat and cover: Plastic
Shipping Weight: 112 lbs.
Shipping Dimensions:
21” x 31” x 34”
Accessories: Sound Experience - THU9201
Connection Unit - THU9202#XX
