Keypad entry with built-in alarm

*24046435*
24046435
KEYPAD ENTRY WITH BUILT-IN ALARM
INSTALLATION INSTRUCTIONS
MODEL FE576
Optional Latch
Faceplate
Batteries
Pin Wrench
Tools Needed
• Phillips screwdriver
Optional Tools
• Tape Measure
• Pencil
• Flathead Screwdriver
• Wood Block
• Hammer
IMPORTANT NOTES
• DO NOT use a power drill for installation!
• Use a screwdriver to remove product from packaging.
• Install and test lock with door open to avoid being locked out.
1
Check Dimensions.
If door dimensions do not match, go to www.schlage.com for drilling
instructions.
2C\,” (60 mm)
OR
2C\v” (70 mm)
2Z\,” (53 mm)
Hole
2
Install strike onto door jamb.
Actual Size (2)
Alarm
Interior
Exterior
Keypad
