3
ROMAN TUB FAUCET
SCRT600
PARTS LISTING
No Part Number Part Name Q'ty
1 A66D422xx Handle Cap 2
2 A004046N O-Ring (Φ1/4" ID * Φ3/8" OD) 2
3 A008041 Screw (3/16" -24 * 7/16" L) 2
4 A069899xx Metal Handle 2
5 A018073xx Handle Base 2
6 A126108 Fixing Set 2
7-a A507376N Ceramic Disc Cartridge-Cold 2
7-b A507375N Ceramic Disc Cartridge-Hot 2
8 A66D423 Handle Trim Ring 2
9 A072032N O-Ring (Φ1-5/8" ID * Φ1-13/16" OD) 2
10 A663951 Mounting Hardware Assembly 2
11-a A002544C Handle Valve Body-Cold 1
11-b A002544H Handle Valve Body-Hot 1
12 A139720xx Spout 1
13 A66D448xx Lift Rod 1
14 A008191 Screw (M4 * 5 mm L) 1
15 A071342xx Spout Trim Ring 1
16 A66D449 Adaptor Assembly 1
17 A072048N O-Ring (Φ1-1/16" ID * Φ1-1/4" OD) 1
18 A004107 O-Ring (Φ1-9/16" ID * Φ1-11/16'' OD) 1
19 A66D450 Mounting Hardware 1
20 A072069 O-Ring (Φ1/8" ID * Φ1/4" OD) 1
21 S2211195xx Hand Shower W/Check Valve 1
22 A604627xx Spray Holder Assembly (3-3/4''L) 1
23 A134036xx Shower Hose (72") 1
24 A105137 Supply Hose 1
25 A031003 Hex Wrench(H2 * 17 mm L * 49 mm L) 1
XX designates finish matched parts
