MADE IN USA
SIX YEAR WARRANTY
AN-Mini/MiniVox Lite Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
AN-MINI TEChNICAL SPECIFICATIONS
(Specifications Subject to Change Without Notice)
Anchor Audio customer service
800.262.4671
For AdditionAL inFormAtion
visit www.anchoraudio.com
hAVING TROUBLE WITh YOUR SOUND SYSTEM?
CONDITION POSSIBLE CAUSE
No Sound (LED off) • turn POWER switch ON
• charge batteries
No Sound (LED on) • turn microphone switch ON
• make sure all cables are completely plugged in
No Sound When Using CD Input • check for output from source
• make sure all cables are completely plugged in
Distorted Sound • lower system/input volume control
• replace or recharge batteries
Shortened Battery Life • replace worn NiMH batteries
• ‘Cycle’ NiMH batteries (see page 5)
Unit Turns Off & Back On During Use • batteries are low and need to be replaced
HAVING TROUBLE WITH YOUR WIRELESS SYSTEM? (Wireless Model Only)
No Sound (RX Indicator: ON) • microphone volume control is to low or off
• no mic plugged into belt-pack transmitter
No Sound (RX Indicator: OFF) • sound system not turned on
• transmitter power switch turned off
• low battery or no battery in transmitter
• transmitter and receiver are not on the same channel
NEED MORE HELP? AN-Mini Setup & Operation Videos!
Visit Our Website: www.anchoraudio.com
Rated Power Output 30 watts
Max SPL @ Rated Power 100 dB @ 1 meter
Frequency Response
100 Hz – 15 KHz +/- 3dB
Speaker Type 4.5 inch neodymium woofer
Battery Type 10 ‘AA’ alkaline
Dimensions (HWD) 5.5” x 5.5” x 6.5”
(13.9 x 13.9 x 16.5 cm)
Weight 2.5 lbs / 1.13 Kg
Line Out line level, 3.5 mm
Inputs
Line
line level, 3.5 mm
Powered Microphone Lo-Z phantom power, 3.5 mm jack
Microphone Lo-Z, 1/4” phone
RC-30 – Recharge Kit (optional)
Battery Type
10 ‘AA’ size, NiMH 2.5 AH
Charger AC-30
AC-30 Input
120 VAC, 60Hz, 24 watts max
AC-30/220 Input 220 VAC, 50Hz, 10 watts max
Shipping Weight 2.1 lbs / 1.0 Kg
