PortaCom tEChNiCaL sPECiFiCatioNs
Operating Distance Up to 2,500 ft (total cable length)
Normal Line Level -15dBV
Signal-to-Noise Ratio -65dB
Distortion < 0.5%
Connecting Cables Standard 1-pair shielded mic cable
w/ 3-pin XLR (heavy-duty cable
recommended for runs over 250 ft)
Compatibility Generally compatible w/ industry
standard system (call for info)
B3-2000 – Branch Box
Connectors
(3-pin XLR) Input – 1 female / Output – 3 male
Dimensions 1.9” x 4.1” x 4.25”
(48 x 105 x 108 mm)
Weight 19.2 oz / 0.5 kg
BP-2000 – Belt pack
Input Line Connector
3-pin XLR – female
Headset Connector 4-pin XLR – male
Bridging Impedance 10k ohm min
DC Current Reqs. 20mA max
Dimensions 3.8” x 2.75” x 1.25”
(96.5 x 69.85 x 31.75 mm)
Weight .40 oz. / 0.0113 kg.
H-2000/H-2000S–Dual-Earpiece/Single-Earpiece Headset
Connector
4-pin XLR – female
Microphone Type Dynamic, low impedance
Dimensions 3.5” x 7.4” x 7.9”
(8.9 x 18.8 x 20 cm)
Weight H-200 16 oz / .45 kg
H-200S 13 oz / .37 kg
PC-2000 – Two-Channel Power Console
Output Connectors
3-pin XLR – 4 male
Voltage Output 22 volts DC to belt packs
Max. Current Capacity 400mA
Max. Belt Packs
20 BP-2000 belt packs
Input Power Reqs. 24VAC, 50/60Hz, 750mA;
30 – 40VDC, 500mA
Dimensions 1.75” x 8.5” x 4.5”
(45 x 216 x 114 mm)
Weight 57.6 oz / 1.63 kg
AC Power Adapter Anchor model AC-20
Input Voltage 120VAC, 60Hz
Output Voltage/Current 24VAC @ 750mA
