Data Sheet
DTA-F
Desk Call Station as Fire Brigade Call Station
www.dvs-21.de
The DTA desk call station consists of the following components:
o
The three-part grey-white desk housing made of ABS
o
The aluminium mounting plate
o
The electrical components:
-
Gooseneck microphone (standard part for call station with call signal,
mounted in top)
-
4 W/6 W loudspeaker (mounted on aluminium plate)
-
Motherboard with 4 W call station amplifier (mounted in housing base)
-
Keypad circuit board with 30 keys (mounted on aluminium plate), for 12
or 30 keys
- Keypad circuit board with 18/36/54 keys (mounted on aluminium plate),
for ≥48 keys
Included with the product are:
-
DTA connecting cable 2.5 m
- Wall connection socket
The interface module, 4NSA (order-no. 2.301), necessary for operation of the call
station, is connected to the wall connection socket with 4 or 6-wire cable and
configured there according to the corresponding plug contacts.
The DTA connecting cable is plugged into the 15-pin D-sub connector of the DTA and
configured according to the corresponding plug contacts of the wall connection socket.
Order Data:
Model – Quantity of
Illuminated Buttons
L-No.
DTA-F-012 1.112
DTA-F-030 1.130
DTA-F-048 1.148
DTA-F-066 1.166
DTA-F-084 1.184
LF interface module
4NSA 2.301
Date: 16.03.2009 Page: 4/6 Author: VS Document-No.: DB_DTA-F_1148_01
