Data sheet, Use2.ob – Procom USE2.OB User Manual
Page 5
Data Sheet
USE2.OB
Interface Attachment for Local Battery Telephony
The Front Plate Symbols and their Meaning:
The System Blinker
Addressing from processor taking place
I/O Input/Output
BUS output works as push-push operation with the system
blinker
BUS input works as push-pull operation with the system blinker
Receiving
Incoming call signal / voice signal recognized
Sending
Outgoing call signal
On Status
Display
Connection exists
Alarm Error Message
Signals an invalid LB call signal
Date:
23.03.2009 Page:
5/6
Author:
HS
Document-No.:
DB_USE2.OB_2730_1
