Data Sheet

MI4M

Microphone Measurement Module

The LF level of the connected microphone determined by the module can
be transmitted to the service PC and displayed in ICS.

2 integration times can be set.

Integration time "Quick” or “Slow” is selected in the configuration software ICS
(depending on set).

A malfunction signal in the case of fuse outage can also be configured in the
ICS. For this a measuring microphone must be set as terminal for the corre-
sponding set.

The Front Plate Symbols and their Meaning:

The System Blinker
Addressing from processor taking place

I/O Input/Output

BUS input works as push-pull operation with the system blinker
BUS output works as push-push operation with the system blinker

Status Measuring

LED illuminated:

measuring taking place

(depending on set)

Fuse

LED off:

Fuse triggered

(depending on set)
