Data Sheet

LCPU

Linux IP Attachment

Applications:

• Screen (management) workplace

- Public address for remote locations over up to 64 DVS-21 systems

as live public address or through stored text files

- Public address of multiple video workstations to the same

destinations

- Assigning of up to 20 priorities per system

- Configuration also as disruption notification PC

• DVS-21 system networking over a LAN (LCPU to LCPU)

• Digital announcement machine (voice storage function)

• VoIP applications for DVS- 21

• Automatic announcement device / passenger information system

(Deutsche Bahn AG)

Details can be found in the application descriptions.

The Front Plate Symbols and their Meaning:

The System Blinker
Addressing from processor taking place

I/O Input/Output

BUS output works as push-push operation with the system blinker
BUS input works as push-pull operation with the system blinker

Receiving

Attachment receiving signal (depending on set)

Sending

Attachment sending signal (depending on set)

Date:

16.03.2009 Page:

4/5 Author:

Document-No.:

DB_LCPU_ 2220_00
