Procom CPR-245 User Manual
Procom, Procom loudspeaker, Cpr-245
Rated power
6 W / 100 V - 10 W / 100 V
Frequency range (-10dB)
50 - 18.000 Hz
SPL @ 1Watt / 1m
98 dB
SPL @ full power / 1m
108 dB
Tappings @ 100 V line
1:1 / 1:0,5 / 1:0,25
Dimensions
Ø 252 mm x 82 mm
Ceiling / wall cut-out
215 mm - 230 mm
Net weight
1,4 kg - 1,5 kg
Colour
RAL9006 silver, RAL9010 white
IP Code
IP 54 / -20° … +90°
Connector,
WAGO clamp,
Fastening
stainless steel spring clips
Hergestellt in Deutschland
Made in Germany
All rights and technical modifications reserved V1.0
ProCom loudspeaker
Metal loudspeaker for ceiling installation
Technical Specifications
Alfredstrasse 157
D-45131 Essen
www.procom-communication.de
Tel.:
+49 (0) 201 860 670 - 90
Fax.: +49 (0) 201 860 670 - 98
[email protected]
Deutschland / Germany
ProCom
Professional Communication
& Service GmbH
ProCom
CPR-245
