133394-2 Rev. B
IQ-PIP-USP2 Adapter
Installation Manual
© 2002 Crown Audio, Inc.
4 Operation
4.1 General Information
This section provides information about using the
IQ-PIP-USP2 in an amplifi er with the IQ-PIP-USP2
Adapter installed.
Important: The IQ-PIP-USP2 Adapter requires IQ for
Windows, version 5.02 or newer. Older versions of
the software will not recognize the adapter and allow
communication with the IQ-PIP-USP2.
4.2 Identifi cation within IQ for Windows
IQ for Windows software recognizes and identifi es
the IQ-PIP-USP2 Adapter itself, rather than the
IQ-PIP-USP2 module.
1. In the “General” tab of the IQ-PIP-USP2 Control
Panel, “USP2APTR” appears as the model.
2. “AFTERMKT” appears as the serial number.
3. The Date Code that appears is the date of
manufacture of for IQ-PIP-USP2 Adapter.
Refer to Figure 4.1.
Figure 4.1 “General” Tab Showing Identifi cation of
IQ-PIP-USP2 Adapter
4.2 Feature Differences
Some standard features of the IQ-PIP-USP2 are
not available when the module is used with the
IQ-PIP-USP2 Adapter.
4.2.1 Fault and Load Error Reporting
Fault and Load Error Reporting is not available. Refer
to Figure 4.2.
Figure 4.2 “Error Reporting” Tab Showing Fault and
Load Error Reporting Disabled
4.2.2 Load Supervision
Load Supervision is not available. Refer to Figure
4.3.
Figure 4.3 “Load Supervision” Tab Showing Load
Supervision Disabled
9
