SPECIFICATIONS
• Power Rating: 120V AC, 60Hz, 313W
• Power Cord: Maximum length: 3.9 ft/120
cm, 3 prong grounded plug
• Water Feature: Adjustable Water Flow Rate:
Front washing - from 9.1 -
19.6 oz/min.
Back washing - from 9.8 -
20.3 oz/min.
• Washing Spray Temp: Minimum: 95˚F/35˚C
Maximum: 104˚F/40˚C
• Water Heater Capacity: 248W
• Water Heater Tank Volume:
0.20 gal./0.78L
• Safety Device: Thermal fuse, bimetal switch
(overheating, auto reset),
fl oat switch (empty tank)
• Back Flow Prevention: Integral backfl ow protection
complies with requirements
in ASSE 1001 as required by
ASME A112.4.2 and ASME
A112.18.1/CSA B125.1
• Seat Warming Feature: Surface Temperature:
Minimum: 86˚F/30˚C
Maximum: 100˚F/38˚C
(W/ Auto Energy Saver
79˚F/26˚C)
• Seat Heater Capacity: 50W
• Safety Device:
Thermal fuse
• Water Supply Pressure: Minimum: 7 psi
Maximum: 110 psi
• Ambient Temperature: Range:
33˚F/1˚C to 95˚F/35˚C
• Weight: Net: 10.6 lbs/4.8 kg
Gross: (w/pkg) 17.4lbs/7.9kg
• Product Dimensions: 18-7/8"W x 20.5"D x
6-3/4"H
• Warranty: One Year Limited Warranty
• Shipping weight: 10.6lbs.
• Shipping dimensions: 23" x 20" x 9"
SW502
Washlet ® B100
# SS-00408 v.01
Printed in U.S.A. | © TOTO USA 07/11 | Printed on recycled paper ♻
Ph: (888) 295-8134 | Fax: (800) 699-4889 | www.totousa.com
INSTALLATION NOTES
• Washlet B100 may not fi t certain toilet bowl designs.
• If possible, with your order, please include your toilet
manufacturer’s name and model number (from the
underside of the tank lid).
These dimensions and specifi cations are subject to change without notice
10-7/8” (278mm) 8” (202mm)
5-1/2”
(140mm)
18-7/8” (480mm)
8” (202mm)
15-7/8” (402mm)
2-1/2”
(65mm)
1-7/8”
11
-3/8” (290mm)
(48mm)
20-1/2” (522mm)
2-1/2” (62mm) 1-5/8” (62mm)
