• Warranty Three year warranty
• Material Bronze with polished
chrome fi nish
• Power Supply Hydropower self-generating
system
• Hot/Cold-water Supply Minimum required water
pressure: 15PSI
Maximum water pressure:
125PSI*
• Water Supply Connect 3/8" Compression
• Water Consumption 0.15 gallons per cycle (max);
• Water Saving Function Automatically turns OFF
when user removes hands
Maximum continuous run
time is 15 seconds
• Detection time ON feature: Immediate
OFF feature: 1 second delay
• Detection range Factory set at 2-1/4"
Faucet automatically sets the
detection range according
to the size of the basin
• Discharge water Thermal Mixing Faucet:
temperature control Cold inlet: 39 - 80°F
range Hot inlet: 120 - 180°F
Adjustable Outlet: 39 - 113°F
(max)
• Anti-scald safety Provides the user protection
feature against exposure to
excessive water temperature
(Thermal mixing faucet, only)
Integrated EcoPower ® Faucet
#SS-00623, v.02
Printed in U.S.A. | © TOTO USA 09/11 | Printed on recycled paper ♻
Ph: (888) 295-8134 | Fax: (800) 699-4889 | www.totousa.com
These dimensions and specifi cations are subject to change without notice
2-3/16"
(56mm)
1-13/16"
(47mm)
1-1/8"
(29mm)
5-15/16"
(151mm)
5" (127mm)
3-13/16"
(97mm)
5-1/16"
(129mm)
13-13/16"
(350mm)
1-5/16" (33mm)
minimum dia.
hole required
20°
2" (50mm)
max deck
thickness
HOT
temperature
mixing lever
COLD
3/8"
compression
fittings
6-1/8" (155mm)
Finished Wall
1-3/8 " (35mm)
minimum gap between finished wall
and behind the spout
TEL5LI
SPECIFICATIONS NOTE
Following the Federal mandate for water effi ciency
outlined in the Environmental Protection Act of 1992,
Faucets can be rated for water consumption based on
two categories: fl ow rate and water consumption.
With the “Water Consumption” standard, a faucet
must not use more than 0.25 gallons of water per
cycle. The TOTO
® faucet with a 15 second cycle uses
0.15 gallons of water. This is a 40% below the base line
of 0.25 gallons per cycle.
Furthermore, an innovative design feature
incorporated into all TOTO electronic faucets is an
"ON-DEMAND" mode. This means that the faucet
will only deliver water as needed and will not run the
entire duration of its rated cycle - 15 seconds. This
guarantees additional water savings.
TOTO uses water consumption because it is the most
accurate method of measuring water use. This method
of measurement can be incorporated into water usage
calculations for various effi ciency programs. For more
information, please consult www.totousa.com.
*Water pressures over 80 psi are not recommended for most
plumbing fi xtures.
Maximum deck thickness 2" (50mm)
