Custom shower
diverter
■ Linden ™ Collection
■ Three Function Diverter Trim (T11894)
■ Six Function Diverter Trim (T11994)
■ Coordinates With All Delta Linden ™
Styled Bath Suites
Submitted Model No.: _____________________________________________
Specific Features: ________________________________________________
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
®
Standard SpecificationS
• Three function diverter. 2 individual positions,
1 shared position.
• Six function diverter. 3 individual positions,
3 shared positions.
• 1/2” rough-in.
• Must also order R11000 rough-in .
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2011 Masco Corporation of Indiana
®
U P
C
DSP-B-T11894 Rev. A
Warranty
• Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from defects
in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
coMpLieS WitH:
• ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
T11894▲ T11994▲
▲ Designate proper finish suffix
T11894▲
T11994▲
4 1/2"
(114 mm)
Dia.
4 1/2"
(114 mm)
5"
(127 mm)
2 1/8"
(54 mm)
2 1/4"
(57 mm)
Supply
C/L Supply Line
2 +3/4/-0"
(51 mm)
4 1/2"
(114 mm)
Dia.
4 1/2"
(114 mm)
5"
(127 mm)
2 1/8"
(54 mm)
2 1/4"
(57 mm)
Supply
C/L Supply Line
2 +3/4/-0"
(51 mm)
