L
Max19-11/16"
(Max 500 mm)
Max31-1/2"
(Max 800 mm)
15
TEU1UN Series
1/8 GPF Urinal EcoPower ® Flushometer Valve
# SS-00484, v.01
Printed in U.S.A. | © TOTO USA 10/11 | Printed on recycled paper ♻
Ph: (888) 295-8134 | Fax: (800) 699-4889 | www.totousa.com
These dimensions and specifi cations are subject to change without notice
SPECIFICATIONS
These specifi cations are subject to change without notice.
*Water pressures over 80 psi are not recommended for most plumbing fi xtures.
Check your local plumbing code for details.
• Warranty Three Year Warranty
• Material Bronze casting
• Power Supply Hydro-Power Charge
• Water Supply 3/4" NPT
• Detection time Factory setting at six (6)
seconds minimum
• Detection range Self-adjusting to environment
• Discharge quantity Preset to 1/8 gpf / 0.47 lpf
• Operating temperature 32°-104°F (0°-40°C)
• Supply water pressure 15 psi - 125 psi*
• Trap seal protection
Automatically fl ushes once
after twelve (12) hours of
non-use
*Check local codes
4-3/4 1/2"
(120 13mm)
3/4"
inlet supply
11-1/2"
(292mm) 1-1/2"
NPSM
Min.2-1/4"(57mm)
3/4"NPT
