Factory Direct Hardware Delta T2794 Linden - Manual

Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
DSP-B-T2794 Rev. A
COMPLETE VALVE COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
Watersense applies to
handshower only.
ROMAN
TUB/WHIRLPOOL
FAUCET TRIM
■ Linden™ Bath Collection
■ Three Hole Installation (T2794 Series)
■ Four Hole Installation (T4794 Series)
■ Rough-In Kit Must Also be Ordered to
Complete Installation (R4707 for four
hole and R2707 for three hole)
STANDARD SPECIFICATIONS:
• Trim only for two handle Roman Tub faucet for
concealed mounting.
• 8 3/8” (213 mm) long, 7 7/8" (200 mm) high
slip-on rigid spout.
• Temperature and volume controlled with handles.
• Rough-In kit must also be ordered to complete
installation (R4707 for four hole and R2707 for three
hole). There are separate specification sheets on
each rough-in kit if more details are required.
• Handshower includes double check valves for
backflow prevention (T4794).
• Handshower flow rate 2.0 gpm @ 80 PSI.
0
1
2
3
4
5
0 10 20 30 40 50 60 70 80 90
Pressure (PSI)
Flow (U.S. Gallons Per Minute)
6
0 69 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flow (Liters Per Minute)
®
®
U P
C
T2794▲
WARRANTy
• Lifetime Faucet and Finish Limited Warranty
to the original consumer purchaser to be free
from defects in material and workmanship.
• 5 Year Limited Warranty for usage in all
industrial, commercial and business applications.
T2794 & T4794
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
T4794▲
5 1/2"
(140 mm)
6 1/4"
(159 mm)
4 3/8"
(111 mm)
3 5/8"
(92 mm)
7 7/8"
(2 00mm)
8 3/8"
(213 mm)
2 3/4"
(70 mm)
59" HS Hose
8" - 16"
(203 mm -
406mm)
Centers
(Flexible)
2 3/8"
(60 mm)
Dia.
3 3/4"
(95 mm)
3 1/8"
(79 mm)
2 9/16"
(65 mm)
Dia.
4"
(102 mm)
7 3/4"
(197 mm)
0
1
2
3
4
5
0 10 20 30 40 50 60 70 80 90
Pressure (PSI)
Flo
w (U
.S.
Gallons P
er Minute)
6
0 69 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flo
w (Liter
s P
er Minute)
5
10
15
20
25
30
18.9
0
0 10 20 30 40 50 60 70 80 90
Pressure (PSI)
Flo
w (U
.S.
Gallons P
er Minute)
0 69 138 207 276 345 414 483 552 621
0
37.9
56.8
75.7
94.6
113.6
Pressure (kPa)
Flo
w (Liter
s P
er Minute)
2.0 gpm @ 80 psi
Kitchen, Lavatory, Bar
17/18/19 gpm @ 60 psi
Roman Tubs
0
1
2
3
4
5
0 10 20 30 40 50 60 70 80 90
Pressure (PSI)
Flo
w (U
.S.
Gallons P
er Minute)
6
Showerhead
0 69 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flo
w (Liter
s P
er Minute)
2.5 gpm @ 80 psi
Showerheads, Hand Held Showers
1.0 gal = 3.785 liters
1.0 psi = 6.895 kPa
Handshower
Roman Tub
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2011 Masco Corporation of Indiana
▲ Designate Proper Finish Suffix
