Exit only Dummy Trim Night Latch Night Latch
Pull when Dogged Key Retracts Latchbolt Key Retracts Latchbolt
Optional Pull Required
Product Description
Trim Description
Escutcheon Plate Size
Pull Center to Center
Projection
ANSI Function
Cylinder Type
Optional Trim
(See pages 32 – 34)
Optional #425 Sex Bolt
Quantity for Device
XP98EO XP98DT XP98NL XP98NL-OP
XP99EO XP99DT XP99NL XP99NL-OP
110NL-MD
110NL-WD
3" x 14 ³ ₁₆" x ³ ₃₂" 3" x 14 ³ ₁₆" x ³ ₃₂"
( 76x360x2mm) ( 76x360x2mm)
–– 5 ¹ ₂" ( 140mm) 5 ¹ ₂" ( 140mm) ––
–– 2" ( 51mm) 2" ( 51mm) ––
01 02 03 03
–– –– Rim Rim
x990EO x991K-DT x991K-NL
x992EO x992L-DT x992L-NL
x994EO x994L-DT x994L-NL
x996EO x996L-DT x996L-NL
x696DT x696NL
x697DT x697NL
6 2 2 6
XP98/99 ™ Rim Exit Device Standard Trim
–– 990DT 990NL-R/V
–– ––
Lever Lever – Night Latch Lever – Blank Escutcheon Lever Dummy Trim
Key Locks & Unlocks Key Retracts Latchbolt Always operable Pull when Dogged
(No Cylinder)
Product Description
Trim Description
Escutcheon Plate Size
Pull Center to Center
Projection
ANSI Function
Cylinder Type
Optional Trim
(See pages 32 – 34)
Optional #425 Sex Bolt
Quantity for Device
XP98L XP98L-NL XP98L-BE XP98L-DT
XP99L XP99L-NL XP99L-BE XP99L-DT
996L-R/V 996L-NL-R/V 996L-BE-R/V 996L-DT-R/V
2 ³ ₄" x 10³ ₄" x ²⁷ ₃₂" 2 ³ ₄" x 10³ ₄" x ²⁷ ₃₂" 2 ³ ₄" x 10³ ₄" x ²⁷ ₃₂" 2 ³ ₄" x 10³ ₄" x ²⁷ ₃₂"
(70x273x21mm) (70x273x21mm) (70x273x21mm) (70x273x21mm)
–– –– –– ––
2 ⁷ ₈" ( 73mm) 2 ⁷ ₈" ( 73mm) 2 ⁷ ₈" ( 73mm) 2 ⁷ ₈" ( 73mm)
08 09 –– 02
Rim Rim –– ––
x992L x992L-NL x992L-BE x992L-DT
x994L x994L-NL x994L-BE x994L-DT
2 2 2 2
