Page 4
English
Installation
Place the faucet and sealing ring on the mounting
surface.
Install the friction washer, metal washer, and
mounting nut.
Tighten the tensioning screws.
Install the pull rod.
Connect the hoses to the stops.
Use two wrenches, as
shown, to prevent hose
twisting.
Install the pull rod.
Install the drain.
Turn on the water and check all connections for
leaks.
