Wallmount Sink Faucets
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue models, both without notice or obligation.
Dimensions are for reference only. See current full-line price book or www.specselectonline.com for finish options and product availability.
DSP–28C/T4 & 6
Refer to www.specselectonline.com for individual models.
Note: Use this page front and back as a product submittal sheet.
Approvals:
• CSA certified
• Complies to ASME A112.18.1
• Lever Blade Handle No.’s 2, 3 and 4,
ADA Compliant and meet
Handicapped Accessibility
Standard ASME A117.1 of less than
5 lbs. operating force.
• IAPMO listed
(Contact Delta Representative for State and/or
Local Approvals.)
FLOWRATE vs PRESSURE
FRONT VIEW
GOOSENECK SPOUTS
SWING SPOUTS
2.5
2
1.5
1
.5
0
0
0
1
2
3
4
5
6
7
8
9
10
20
30
40
50
60
70
80
Line Pressure (psig)
FLOW
(l/min.)
FLOW
(USGPM)
Spout Outlets
No. 3 & 4 Aerator
No. 2 Laminar Flow Outlet
No. 1 Rose Spray
INLETS - 1/2'' FIP/MIP
Note: Measurements may vary ± 6mm (0.25'')
INLETS: 1/2-14 NPT (FEMALE)
OR 1/2-14 NPT (MALE) - WITH SUPPLIED NIPPLE
203
±
6mm
(8.0"
±
0.25")
51mm
(2.0")
76mm
(3.0")
91mm
(3.6")
OUTLET
“D”
NO.
mm
in.
1
17
0.67
2
18
0.69
3
18
0.69
4
17
0.67
ADJUSTABLE CENTERS
❏ Add Suffix “AC” to Product Number
See Page 9.C.1 for
additional optional
spouts.
GOOSENECK SPOUT ASSEMBLIES
Spout
“A”
“C”
“L”
No.
SPOUT TYPE
mm
in.
mm
in.
mm
in.
9
Gooseneck–Standard (R4)
152
6
124
4.9
146
5.8
Spout
“A”
“C”
“L”
No.
SPOUT TYPE
mm
in.
mm
in.
mm
in.
1
8" Wallform Spout (S2)
206
8.1
15
0.6
130
5.1
2
8" Tubular Spout (S5)
185
7.3
41
1.6
147
5.8
4
11" Tubular Spout (S7)
277
10.9
28
1.1
104
4.1
See Page 9.C.2 for
additional optional
spouts.
SWING SPOUT ASSEMBLIES
(2.50")
64mm
1/2-14 NPT
MALE
1/2-14 NPT
FEMALE
A
L
D
41mm
(1.6")
C
96mm
(3.77")
102mm
(4.0")
114mm
(4.5")
89mm
(3.5")
132mm
(5.2")
102mm
(4.0")
4
3
2
(2.50")
64mm
1/2-14 NPT
MALE
1/2-14 NPT
FEMALE
A
L
C
D
51mm
(2.0")
1/2-14 NPT
FEMALE
140-267mm
(5.5" - 10.5")
51mm
(2.0")
