Installation
Turn off the water at the main
before beginning.
Cut the plaster shield so that it extends ⅜" above the
surface of the finished floor.
Remove the flush insert.
Do not discard the screws.
(1) Position the tub filler on the rough.
(2) Pivot the tub filler, if necessary.
(3) Make sure that the tub filler is level.
(4) Connect the tub filler to the rough using the 6
screws (3 included with the tub filler, 3 reserved from
the flush insert).
1
4
3
2
8 mm
8 mm
1
2
3
