27454 Wall Outlet
Installation
This unit requires a 1/2” male threaded pipe fitting extending 3/4” outside
the surface of the finished wall.
Wrap the pipe fitting with two layers of Teflon
TM
thread tape. Seal the wall
around the pipe fitting with silicone.
Install the female end of the elbow through the gasket and onto the fitting.
Test for leaks.
Install the cover over the elbow and snap into place on the gasket.
Install the handshower hose.
Care Instructions
Regular cleaning with a mild soap/water solution and a soft cloth will
keep your finish looking new. Rinse thoroughly with clear water and polish
dry with a soft cloth.
Do not use cleaners containing solvents, acids, or abrasives.
Backflow Prevention
This wall outlet does not include a backflow prevention
device, which is required by code in many areas. We recommend the use
of Hansgrohe model 06510 vacuum breaker or a comparable device. The
Hansgrohe 06510 vacuum breaker should be installed between the hose
and the wall outlet, NOT between the handshower and the hose.
