Select Location
Your bar unit is a beautiful bath
accessory and should be located
so it looks good and performs
as intended. Pictured are some
typical installations as suggestions
only, pick a location that suits your
family’s needs.
Select a convenient height based
on your family’s needs. Note:
Locate so there will be slack
in the hose when shower is in
extreme up or down position.
2.
1.
Select Location
Remove bar mount from bar. Place in
marked position on wall and mark center
screw hole on wall. Do not mark lower
mount at this time.
Mounting Bar
4. 2. 3.
Draw circle around top mount with soft
pencil.
Position bar on wall at desired position. Place end mount of wall bar into the
mount - do not tighten the set screw.
5.
Place bar into mount. Do not tighten
Allen set screw.
8. 6. 7.
Insert screw anchor. Drill hole for top mount. Use 1/4 inch
carbide drill for ceramic tile.
Secure mount to wall with screw. Note:
Allen set screw must be at top of mount.
9. 10. 11.
Tighten Allen set screw on both top and
bottom mounts.
Remove bar from both mounts. Secure
lower mount to wall as in steps 7-9 with
Allen set screw facing down. Replace
bar onto mounts. Check alignment with
level. If not plumb, remove bar, loosen
mount screws and adjust accordingly,
retighten screws and replace bar.
Align bar and mark bottom as in step 5.
CAUTION:
Delta ® Wall Bars are not
to be used as grab bars!
