Cast Deckmount Sink Faucets

8” Centers

Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue models, both without notice or obligation.

Dimensions are for reference only. See current full-line price book or www.specselect.com for finish options and product availability.

DSP–26C3/T Rev. A

Refer to www.specselect.com for individual models.

Note: Use this page front and back as a product submittal sheet.

GOOSENECK SPOUT ASSEMBLIES

“A”

“C”

“L”

SPOUT/OUTLET

mm

in.

mm

in.

mm

in.

Gooseneck–Standard (R4) for outlets #2, 3, 4

152

6

124

4.9

146

5.8

Gooseneck–Standard (R4) for outlets #7

152

6

117

4.6

152

6.0

See Page 9.C.1 for
additional optional
spouts.

Spout

“A”

“C”

“L”

No.

SPOUT TYPE

mm

in.

mm

in.

mm

in.

1

8" Wallform Spout (S2)

206

8.1

15

0.6

130

5.1

2

8" Tubular Spout (S5)

185

7.3

41

1.6

147

5.8

Approvals:
• CSA certified
• Complies to ASME A112.18.1
• Lever Blade Handles No. 2, 3, 4, and 5,

ADA Compliant and meet Handicapped
Accessibility Standard ASME A117.1
of less than 5 lbs. operating force.

• IAPMO listed
(Contact Delta Representative for State and/or

Local Approvals.)

FLOWRATE vs PRESSURE

SWING SPOUT

FRONT VIEW

2.5

2

1.5

1

.5

0

0

0

1

2

3

4

5

6

7

8

9

10

20

30

40

50

60

70

80

Spout Outlets

No. 3 & 4 Aerator

No. 2 Laminar Flow Outlet

Lin e Pressu re (ps ig)

FLOW

(l/min.)

FLOW

(USGPM)

No. 7 Flow Control

Outlet Flowrates

OUTLET

“D”

NO.

mm

in.

2

18

0.69

3

18

0.69

4

17

0.67

89mm

(3.5")

102mm

(4.0")

117mm

(4.6")

203mm

(8.0")

267mm

(10.5")

25mm

(1.0") MIN.

2 HOLES

44mm

(1.75") MAX.

DECK THICKNESS

97mm

(3.8")

102mm

(4.0")

96mm

(3.77")

51mm

(2.0")

27mm

(1.06")

A

D

C

L

See Page 9.C.2 for
additional optional
spouts.

SWING SPOUT ASSEMBLIES

GOOSENECK SPOUT

Outlets #2, 3, 4

Outlet #7

51mm

(2.0")

30mm

(1.2")

A

C

L

D

A

L

51mm

(2.0")

30mm

(1.2")

C

87mm

(3.4")

76mm

(3.0")

76mm

(3.0")

4

2

1

3

INLET FOR 3/8”

OR 1/2” FLEXIBLE

RISER OR 1/2-14

NPSM COUPLING

NUT (SUPPLIED)

LIMITED SWING

GOOSENECK

Add suffix “- LS” to Product
Number for 120º Limited Swing

INLETS - 1/2'' MIP/Coupling Nuts

Note: Measurements may vary ± 6mm (0.25'')

141mm

(5.5")

135mm

(5.3")

152mm

(6.0")

5

HANDLE TEMPERATURE

INDICATORS

Add suffix “-TI” to Product Number
for handle temperature indicators
“H” (red), “C” (blue).
Available on handle options 2, 3,
or 4 only.
