Factory Direct Hardware Hansgrohe 18020001 User Manual
Page 3
3
Installation
Position the faucet and sealing ring on the mounting
surface.
From beneath the mounting surface, install the fiber
washer, metal washer, and mounting nut. Tighten the
tensioning screws.
Install the adapters on the stops. Install the filters on the
adapters.
Slide the compression nut, cone washer, metal washer,
and rubber washer over the end of the supply hose.
Place the supply hose in the filter.
