Page 3
3
Installation
Place the faucet on the mounting surface.
If the mounting surface thickness is 1 7/8” or less,
install the plastic washer, friction washer, metal washer
and mounting nut. Tighten the mounting nut. Tighten
the tensioning screws.
plastic washer
friction washer
metal washer
mounting nut
tensioning screws
friction washer
metal washer
mounting nut
tensioning screws
If the mounting surface is 1 7/8” - 3/4”, omit the
plastic washer.
Remove the spout set screw.
