Dexter Laundry SWD EXPRESS - Washer (On-Premise) - Manual (Page 7)

SPECIFICATONS
MODEL STACK WASHER/DRYER 30LB EXPRESS WASHER
CAPACITY
CYLINDER SIZE
ELECTRICAL
DRIVE SYSTEM
WASH SPEED
INTERMEDIATE
EXTRACT
FINAL EXTRACT
MACHINE CONTROL
WATER INLET
DRAIN VALVE
30LBS/4 CUBIC FT. (13.6 kg/113 L)
25” DIA X 14 1/8” DEEP (63.5cm X 36cm)
208-240 VAC, 60 HZ, 1 OR 3 PHASE OR
208-240 VAC, 50HZ, 1 PHASE
SOFT START REVERSING INVERTER DRIVE, 2 HP MOTOR
50 RPM
411 RPM (60 G’S)
SZ MODEL - 750 RPM (200 G’S)
ST MODEL - 532 RPM (100 G’S)
PROGRAMMABLE COMPUTER WITH 6 STANDARD CYCLES.
2 SOLENOID OPERATED VALVES
FLOW RATE: 9 GAL/MIN (34L/MIN) EACH, 30-120 PSI (207kPa-
827kPa)
3” (76mm) DIAMETER
