The washer control may be programmed to send 120V (60Hz) or 24V (50 Hz) output signals for a
chemical injection system. The signals are not intended as a power source and must be limited to
less than 100 milliamps of current. There is a separate terminal block for connection of the external
injection signals. For the injection sources, program codes 0 through 6 are as shown in the table
below.
Dexter
Recommended
Connections
Controller
Programmed
Signals
Injection
Terminal Block
Circuits
Detergent 1 A
Bleach 2 B
Starch 3 C
Sour/Softener 4 D
5 A and B
6 C and D
0 None
CHECKOUT
After all mounting, plumbing and electrical work is completed, the washer should be run through a
cycle and checked for water leaks and proper functioning.
