Maintenance Requiring Technical and Mechanical Skills:

(Disconnect power to dryer before beginning.)

Quarterly

A. Check tumbler shaft retaining bolt for tightness.

B. Check belts for wear needing replacement.

Semi-Annually

A. Clean burners. Note position of back panel of burner housing before removing

as the panel is slotted for adjustment of ignitor to top of burners. This spacing
is to be 5/16 in (8mm).
Mark position of panel on left and right burner side panels for reference.
Remove the burner-housing panel (wires can be left attached and panel left
hanging.)

Blow out burners and around vent opening and orifices with compressed air.

Replace panel in its original position.

Run the dryer to assure operation and ignition and purge any dislodged lint

from drying chamber.

B. Remove front panels and clean all accumulated lint and dirt from all openings

accessible from front.

ANNUALLY

A. Check intermediate pulley bearings for wear.

B. Check and remove any lint accumulation from exhaust system.

SERVICE PARTS

PART NUMBER

DRIVE BELT, MOTOR

9040-077-001

DRIVE BELT, TUMBLER

9040-073-009

LINT SCREEN FILTER

9555-057-002

For service and parts information, contact your local Dexter agent. To find your local Dexter
agent, use the Distributor Locator at the website shown below. If a Dexter agent is not available,
contact Dexter Laundry, Inc. directly as listed below:

Mailing Address:

2211 West Grimes Avenue

Phone: 1-800-524-2954 (USA)

Fairfield, IA 52556

USA
