AXM761-A
SFP+, 10GBASE-SR 10G Ethernet Module
850mn, 300m, MMF, LC RoHS6
_______________________________________________________
Approved Optics, Inc. www.ApprovedOptics.com Page 5 of 8
Optical Characteristics
General Parameters
Parameter Conditions
Bandwidth
Min Modal
(MHz*km)
Symbol Min
Typical
1GBd Typical
10GBd
Units
Operating
Range
62.5 μm MMF
50 μm MMF
62.5 μm MMF
50 μm MMF
50 μm MMF 160
400
200
500
2000
lOP
2
2
0.5
0.5
0.5
220
500
275
550
X
26
66
33
82
300
m
Optical Transmitter
Parameter Optical
Transmitter Conditions
Symbol Min Typ Max Units
Nominal Wavelength  840 850 860 nm
Spectral Width
Fiber Channel version

0.65
Ethernet version 0.45
Average Launch
Power
Pavg -7.3 -1 dBm
Average Launch
Power Fiber Channel version
POMA
-5.2
Ethernet version -4.3
Extinction Ratio ER 3.5 dB
Ethernet 1.25GBd
tbd
Relative Intensity
Noise
RIN -128 dB/Hz
Optical Receiver
Parameter Conditions Symbol Min Typ Max Units
Maximum Input
Power
PMAX -1 dBm
Center Wavelength  840 850 860 nm
Receiver Sensitivity
Ethernet
Pavg, PRBS 2 31 -1, BER
< 1*10-12@ 1.25GBd *)
PIN tbd dBm
OMA, PRBS 2 31 -1, BER
< 1*10-
[email protected] -11.1
Receiver Sensitivity
Fiber Channel OMA, PRBS 2 31 -1, BER
< 1*10-12@2GBd
-13.0
OMA, PRBS 2 31 -1, BER
< 1*10-12@4GBd
PIN
-12.0
dBm
OMA, PRBS 2 31 -1, BER
< 1*10-12@8GBd
-11.2
