AXM761-A
SFP+, 10GBASE-SR 10G Ethernet Module
850mn, 300m, MMF, LC RoHS6
_______________________________________________________
Approved Optics, Inc. www.ApprovedOptics.com Page 3 of 8
Recommended Operating Conditions
Parameter Conditions Symbol Min. Typical Max. Unit
Operating Case Temperature altitude of < 3km JCase 0 +70 °C
Power Supply [email protected] Vcc3 3.135 3.30 3.465 V
DC Common Mode Voltage Vcm 0 3.6 V
Low Speed Characteristics
Parameter Conditions Symb
ol
Min Typ Max Unit
s
Supply Current Transmitter
@ VCCTX
IVCCT
X
120 mA
Supply Current Receiver
@ VCCRX
IVCC
RX
125 mA
Power Consumption 0.65 1 W
TX_Fault, RX_LOS
Host Vcc Range
2V – 3.47V
VOL 0 0.4 V
VOH
Host_ Vcc –
0.5
Host_ Vcc
+0.3
TX_Dis, RS0, RS1 Low Voltage TTL VIL -0.3 0.8
VIH 2.0
VccT +0.3
SCL, SDA
Host Vcc Range VIL -0.3 VccT*0.3
3.14V – 3.47V
VIH VccT*0.7
VccT +0.5
VOL 0.0 0.4
VOH
Host_ Vcc –
0.5
Host_ Vcc +0.3
SFI Module Transmitter Input Characteristics
Parameter Conditions Symbol Min Typ Max Units
Supported Data Rate VID 1 10.3125 11.3 Gbd
Reference Differential Input
Impedance
Zd 100 
Input AC Common Mode
Input Voltage
0 25
mV
(RMS)
