Chapter Five: Appendix
1 Specifications
*VIDEO LOST HANDLING
After the slected video channel being lost, the incident could be linked to those handling : " ALARM OUT " / "
Buzzer " / " UPLOAD "
*CHANNEL NAME SETTING
After the slected video channel being lost, the incident could be linked to those handling : " ALARM OUT " / "
Buzzer " / " UPLOAD " User can input the channel name through the soft keyboard. It only support letters,
select the 【OK】to confirm the settings.
Table V 1 Specifications
DVR Type 16 channel DVR Specifications
System
Linux 2.6 O/S
Pentaplex operation: record, playback, preview and network
browse, backup supported.
I/O Interface
VGA Output
Video Input
1 channel, DIN-15(optional); 800×600@60Hz、
1024×768@60Hz、1280×1024@60Hz、1440×900@60Hz
16 channel, BNC, 1Vp-p，75Ω
PAL (625 line, 50 f/s), NTSC (525 line, 60 f/s), SECAM
(625 line, 50 f/s)
CVBS Output 1 channel, BNC, 1Vp-p，75Ω
Audio Output
Audio Input
Video & Audio
Video
Audio
Environmental
Video Compression
Video Standards
Video Compression
Resolution
H.264 Baseline
PAL/NTSC/SECAM
PAL:352×288（CIF）NTSC: 352×240（CIF）
Audio Compression
Input/Output
Sampling Rate
Audio Channel Type
Sampling Bit
G.726 ADPCM
8KHz
Power Supply
DC 12V 5A，positive inside, negative outside,
power adapter is connected outside.
Operating
Temperature
0℃－+50℃
Operating Humidity 10％～90％RH
Power Consumption <12W（without HDD）
Dimension
13.9in (W) x 10.8in (D) x 1.85in (H) / 354mm (W)
x 275mm (D) x 47mm (H)
Mono
16 bit
PAL: 352×288（CIF），horizontal line 300, vertical line 250
NTSC: 352×240（CIF），horizontal line 300, vertical line 220
32kbps-2048kbps（14M byte/hour - 922M byte/hour）.
PAL：720×576（D1），horizontal line 550, vertical line 450
NTSC：720×480（D1），horizontal line 550, vertical line 400
Video & Audio
Frame Rate
Video Output Bit Rate
Preview Resolution
Playback Resolution
PAL:25F/S/CH 1，3，6，12，25 and user-defined optional;
NTSC: 30F/S/CH 1，3，7，15，30 and user-defined optional.
USB Interface
1 channel, RCA, 2Vp-p, 600Ω
4 channel, RCA, 2Vp-p，600Ω
Support USB storage device, USB mouse, USB burner.
RS485 1 port, receiving and transmitting duplex supported.
Network Interface 4RJ45 10/100M self-adaptive.
Alarm Input 4 channel NO/NC.
Alarm Output 1 channel NO/NC, relay: 30VDC/1A，125VAC/1A
SATA Interface 2 SATA port, 2 SATA HDD up to 2T supported.
