R&M Materials Handling ELECTRIC CHAIN HOISTS Digichain - Manual (Page 9)

R&M Materials Handling, Inc LoadMate Chain Hoist
Springfield, Ohio USA DIGICHAIN Instruction Manual
: 800 955-9967 June 2003
www.rmhoist.com
10/16/03 RM-LM-DIGICH-MAN-2003-0-ENG.doc
9
Item Part Number Description Qty Specification
1 ---- Upper cable fastener 2
2 ---- Thread rolling screw M8x12 2
3 833498 Coiled electric cable with plug 1
-- 7285035 Electrical plug (not shown) 1
4 ---- Clamping shoe 2
5 ---- Parallel pin 4x12 1
6 ---- Support pin 1
7 ---- Lower cable fastener 1
8 ---- Screw TC M3x8 ZN DIN84 3
9 ---- Strap 2.3x99 PLT1mm 1
10 ---- Sleeve 1
11 ---- Screw CHC M6x45 ZN DIN912 2
12 ---- Nut M6 DIN985 2
13 52302277 Black gland ISO M20 1
14 52302285 Nut DIN 936 1
15 ---- Upper pendant enclosure 1
16 ---- Screw CHC M4x20 DIN 912 4
17 ---- Nut HM4 DIN934 4
18 ---- Pendant box module 1
19 833572 Emergency Stop Contact XAC-S 414 1
20 ---- Screw M2.9x9.5 DIN7981 2
21 2309417008 Contact XEN-G 1191 2
22 ---- Screw M2.9x13 DIN7981 4
23 833765 Emergency Stop ZA2 BS44 1
24 2309417044 White button XAC A9411 1
25 2309417044 Black button XAC A9412 1
26 ---- Screw M2.9x19 DIN 7981 4
27 ---- Lower pendant enclosure 1
28 ---- Screw M3.5x16 DIN7981 12
29 ---- Hook shoe 1
30 ---- Drilled hook shoe 1
31 ---- Screw CHC M6x20 DIN912 2
32 ---- Nut M6 DIN985 2
33 8010512 Screw CHC M5x12 DIN912 1
34 2212011 Hook 0T5 1br. 1
35 52300975 Sticker up/down 1
36 7285035 Electrical plug 1
- 52304342 Complete DigiChain unit 1
- 2211050 Fall stop assembly LM05 (not shown) 1
- 52264313 Fall stop assembly LM1 (not shown) 1
