1.5 Setup
Direction
4 screws lock the handle
around the sleeve.
The handle can be turned
and locked 45° from the
position shown, in either
direction.
Hook locking screw –
prevents the hook from
rotating.
To remove the hook block
assembly, remove the two
screws on the block.
Top View
