8
OPERATION
1. General Information: The 4 in 1 Cable Tester
performs its tests when the single button on its
front panel is pressed and released.6 Status
LEDs indicate the condition of the cable being
tested, as well as informing the user that
Power is turned on, and that the battery is
good (or bad).8 additional connection LEDs
light to indicate that specific wires in a cable
are connected.
Note: Only one cable can be tested at a time. i.e.
A BNC cable and an RJ-45 cable cannot be
tested simultaneously.
2. The MAIN and REMOTE unit: The 4 in 1
Cable Tester consists of a Main unit and a
Remote unit .The Remote unit stores
conveniently on the bottom of the Main unit. It
can be removed or replaced by sliding it from
left to right or right to left respectively. Use
care when removing or replacing the Remote.
Some of the plastic edges are a little sharp.
The Remote is often attached to the Main unit
when storing, when transporting, or when
patch cables are being tested. The Remote is
removed from the Main unit when an installed
(in wall, ceiling, etc.) cable is being tested.
3. Testing Patch cables:
“Patch” cables have both ends accessible at
the same location. Usually, but not always,
these cables are less than 25ft in length, and
