Names of Parts
Operation
1. Press the On/Off key to turn on the Power Meter
2. Press
the λ key to set wavelengths that you want to measure.
3. Connect the optical net to be measured, and then reading will be displayed on
the LCD screen, including Linear and nonlinear value.
4. Relative power measurement. Press dB key, then current power value is stored
as a reference value in dB unit.
Optic Network System
6
1. Multi-connector (ST, FC, SC
three in one)
2. LCD.
3. Power ON/OFF button.
4. Function button keypad.
5. Back-light push button.
6. Battery cover
