Spare parts list sp 125 hyd – MAX Power HYD125 Hydraulic Tunnel Thruster User Manual
Page 10
MANUAL SUPER POWER Series 125 HYD 01/05/2004
SPARE PARTS LIST
SP 125 HYD
N° DESCRIPTION
Composite Leg
MPHYC800
Classic Leg
MPHY0800
REFERENCES
3 Motor fixing bolts
4
4
MPOP 5240
4 Hydraulic motor
1
1
MPHY 6010
5 Adapter plate
1
1
MPHY 5012
8 Upper shaft coupling Hydraulic type
1
1
MP205027
10 Rubber
coupling
1
1
MP205023
11 Shaft drive key
1
1
12 Lower
shaft
coupling
1
1
MP205029
13 Motor support + heightening
(composite)
1 1
MP088120
15 Composite drive leg
1
MP08 8100
16 Drive shaft seal
1
MPOP 2030
17 Drive shaft
1
MPOP 4060
18 Top drive shaft bearing
1
MPOP 5250
19 Lower drive shaft bearing
1
MPOP 5251
20 Upper gear
1
MPOP 5051
21 Clip
1
MPOP
5280
22 Composite Fixing Bolts
2
MPOP4130
22 Fixing screw
2
MPOP 5340
23 Fibre joint leg / tunnel 1,5 mm
1
1
MPOP 2060
24 Leg housing
1
MPOP 5270
25 Propeller D 185
2
2
MPOP 8080
27 Propeller
pin
2
2
MPOP
5221
28 Oil seal
2
MPOP 2070
29 Screw Cap
4
MPOP 5320
30 Propeller
shaft
1
MP08
5020
31 Shaft key
1
MPOP 5290
32 Lower
gear
1
MPOP5061
33 Shim
2
MPOP
5350
34 Propeller shaft bearing
2
MPOP 5260
35 O-ring
2
MPOP
2040
36 Cap
2
MPOP
5380
37 Copper washer
1
MPOP 2050
38 Drain plug
1
MPOP 5300
39 Anode
1
MPOP
5390
40 Anode screw
1
MPOP 5311
41 Complete bronze drive leg
1
MP088040
9
